Raspberry Pi Pico H

The Raspberry Pi Pico H is a powerful and flexible microcontroller board built around Raspberry Pi’s first in-house silicon, the RP2040. Designed for embedded projects, prototyping, and production use, Pico H delivers high performance at low power consumption in a compact form factor.

At its core is a dual-core ARM Cortex-M0+ processor running at up to 133 MHz, supported by 264 KB of SRAM and 2 MB of onboard Flash memory. The board offers a wide range of connectivity and peripheral options, including USB 1.1 support, multiple communication interfaces, analog inputs, and programmable I/O for custom hardware control.

The Pico H variant comes with pre-soldered headers, making it ideal for breadboarding, rapid development, and educational use. With drag-and-drop USB programming and support for C/C++ and MicroPython, it’s an excellent choice for both beginners and advanced developers.

Key Features:

• RP2040 microcontroller designed by Raspberry Pi (UK)
• Dual-core ARM Cortex-M0+ processor, up to 133 MHz
• 264 KB SRAM and 2 MB onboard Flash memory
• Pre-soldered headers for easy prototyping (Pico H version)
• USB 1.1 host and device support
• Drag-and-drop programming via USB mass storage
• 26 multi-function GPIO pins
• Interfaces: 2× SPI, 2× I²C, 2× UART
• 3× 12-bit ADC inputs
• 16 controllable PWM channels
• 8 programmable I/O (PIO) state machines for custom peripherals
• Built-in real-time clock (RTC) and temperature sensor
• Low-power sleep and dormant modes
• Board dimensions: 51 mm × 21 mm
