SEN0330, Temperature and Humidity Sensor, 2.15 V to 5.5 V

The SEN0330 is a highly accurate and low-power temperature and humidity sensor featuring the SHT40. With a wide detection range and fast response time, it is perfectly suited for mobile or wireless battery-powered applications. Designed for diverse environments, the SEN0330 is ideal for urban monitoring, intelligent buildings, and Internet of Things (IoT) applications.

Key Features:

• Wide Measurement Range: Humidity: 0 to 100%RH, Temperature: -40°C to 125°C (-40°F to 275°F).
• High Accuracy: ±1.8% RH for humidity and ±0.2°C for temperature measurements.
• Fast Response Time: 8 seconds (tau63%).
• Low Power Consumption: Operating current of 0.45mA, ideal for battery-driven applications.
• Compact Design: Dimensions of 14×17mm with M2 mounting holes for easy installation.
• I²C Communication Interface: Ensures seamless integration with various microcontrollers.
• Built-in Heater: Enables operation in extreme conditions like condensing environments.

Applications:

• Intelligent buildings and smart furniture.
• Weather monitoring stations.
• Warehouse environmental control.
• Animal and plant care systems.
• Germinating boxes for plant seeds.
• Animal incubators.
