AH3-2 ,30M ,110VAC Analog Timer – Multi-Range Time Delay Relay, DPDT Contacts

The AH3-2 30M 110VAC Analog Timer is a high-precision, multi-range time delay relay designed for industrial and automation applications. It operates on a 110VAC power supply and offers an adjustable timing range of up to 30 minutes. This timer utilizes a customized CMOS IC for enhanced reliability, low power consumption, and precise time control. The DPDT (Double Pole Double Throw) output contacts provide stable and efficient operation, making it ideal for applications such as process control, sequential circuits, and automation systems. With a compact and robust design, it ensures long operational life and high electrical performance.

Key Features:

• Multi-Range Analog Timer – Adjustable time delay settings for a variety of applications.
• 110VAC Operating Voltage – Compatible with industrial automation and electrical control systems.
• DPDT Output Contacts – Double Pole Double Throw relay ensures reliable switching with a contact rating of 250VAC, 5A.
• Precision Timing Circuit – Built-in CMOS IC technology provides accurate time delay control with minimal errors.
• Long Electrical and Mechanical Life – Ensures durability with 100,000 electrical operations and 5,000,000 mechanical operations.
• Compact and Easy Installation – Can be mounted using standard PF083A(E) or P3G-08 sockets.

Additional Specifications:

• Type: Time Delay Relay
• Operating Supply Voltage: 110VAC
• Timing Range: 0.1S– 30Min
• Display Type: Dial Indicator
• Accuracy: ±1%
