The SparkFun Educator Lab Pack for micro:bit v2 is a complete classroom-ready learning kit designed to help educators introduce students to programming, electronics, and physical computing. The pack includes 10 micro:bit v2 boards along with cables, battery holders, servos, speakers, jumper wires, and alligator leads, giving students the hardware needed to begin experimenting without sourcing extra components separately. SparkFun Electronics
The micro:bit v2 features a 64 MHz Arm Cortex-M4 processor, 512KB Flash, 128KB RAM, a 5×5 LED matrix, programmable buttons, microphone, speaker, motion and environmental sensors, Bluetooth 5.0, GPIO connectivity, and support for popular programming environments including MakeCode, Python, Scratch, and C++. SparkFun Electronics
Key Features
• Complete classroom pack designed for up to 10 student workstations
• Includes 10 micro:bit v2 development boards
• Suitable for coding, electronics, STEM, and physical computing education
• 64 MHz Arm Cortex-M4 processor with FPU
• 512KB Flash memory and 128KB RAM
• Built-in 5×5 red LED matrix
• Two programmable buttons and touch-sensitive logo
• Integrated microphone with LED indicator
• Built-in speaker for audio projects
• Integrated light, compass, accelerometer, and temperature sensors
• Bluetooth 5.0 and 2.4 GHz micro:bit radio connectivity
• 25-pin edge connector for expansion and accessories
• GPIO, PWM, I2C, and SPI interface support
• Programmable using MakeCode, Python, Scratch, and C++
• Designed for classroom experiments, interactive projects, robotics, and creative coding SparkFun Electronics
Kit Includes
• 10 × micro:bit v2 Boards
• 10 × Small Servos
• 10 × Mini Speakers
• 10 × micro:bit Battery Holders for 2 × AA Batteries
• 10 × USB Micro-B Cables – 6 ft
• 10 × Alligator Test Lead Packs
• 10 × Jumper Wire Packs – 7 in. Male-to-Male, 30 wires per pack SparkFun Electronics
Technical Specifications
• Processor: 64 MHz Arm Cortex-M4 with FPU
• Flash Memory: 512KB
• RAM: 128KB
• Display: 5 × 5 Red LED Array
• Controls: 2 Programmable Buttons + Touch-Sensitive Logo
• Microphone: Built-In MEMS Microphone
• Speaker: Built-In
• Sensors: Light, Compass, Accelerometer, and Temperature
• Wireless: 2.4 GHz micro:bit Radio / Bluetooth 5.0
• Expansion: 25-Pin Edge Connector
• Interfaces: GPIO, PWM, I2C, SPI
• Digital/Analog I/O Rings: 3
• Power Rings: 3V and GND
• USB: MicroUSB 5V
• Battery Connector: JST-PH 3V
• Accessory Current: Up to 200 mA
• Programming: C++, MakeCode, Python, and Scratch SparkFun Electronics
Applications
• STEM Education
• Classroom Coding Lessons
• Electronics Education
• Physical Computing
• Robotics Projects
• Sensor Experiments
• Interactive Projects
• Creative Programming
• Beginner Microcontroller Training
• Maker and Engineering Education
