Siglent SSA3075X-R, Real‑Time Spectrum Analyzer, 9 kHz–7.5 GHz, RTBW up to 40 MHz

The Siglent SSA3075X‑R is a real‑time spectrum analyzer covering 9 kHz to 7.5 GHz. Equipped with a standard 25 MHz reconfigurable real‑time bandwidth (upgradeable to 40 MHz), it offers multi-dimensional analysis (density, spectrogram, PvT, 3D) and full‑time signal capture with zero miss (100% POI, 7.2 µs). Standard features include a low-noise tracking generator, preamplifier, vector network analysis, distance-to-fault, and a 10.1‑inch multi‑touch display with mouse/keyboard support. Expanded modes—modulation analysis, EMI receiver, reflection, and advanced measurements—are available via options. Remote control via LAN or USB with SCPI support facilitates seamless integration.

Key Features

• Frequency span from 9 kHz to 7.5 GHz
• Base real‑time bandwidth of 25 MHz; upgradeable to 40 MHz
• Zero‑miss real‑time capture: immediate time resolution of 7.2 µs
• Multi-view display modes: density, spectrogram, PvT, and 3D
• Includes tracking generator and preamplifier as standard
• Built-in VNA and Distance-to-Fault (DTF) measurement modes
