KDS196S, Fast Switching Diode, SOD-123FL

The KDS196S is a surface-mount, fast recovery diode designed for high-speed switching applications such as DC-DC converters, flyback circuits, and snubber networks. Housed in a compact SOD-123FL package, it provides excellent electrical performance in space-constrained designs. With a high reverse voltage of 600 V and a 1 A forward current rating, it is suitable for a wide range of power electronics and switching power supply applications.

Key Features:

• Fast Recovery Time: Designed for high-speed switching with <75 ns recovery time.
• High Reverse Voltage: Withstands up to 600 V reverse voltage.
• Moderate Current Handling: Continuous average forward current up to 1 A.
• Compact SMD Package: SOD-123FL enables efficient space utilization in surface-mount applications.
• Low Reverse Leakage: Enhances performance in high-efficiency circuits.
• High Surge Capability: Handles surge currents up to 30 A.

Additional Specifications:

• Mounting Style: Surface Mount
• Maximum Peak Reverse Voltage (VRRM): 600V
• Forward Average Current (If): 1A
• Forward Voltage (Vf): 1.2V At 1A
• Maximum Surge Current: 30A
• Reverse Current (Ir): <=5µA At 600V
• Operating Temperature Range: -55+150°C
• Dimensions: 3.7x1.6x1Mm
