MDS 50-12, Three-Phase Rectifier Bridge Module

The MDS 50-12 is a three-phase rectifier bridge module designed for efficient AC to DC conversion in industrial applications. With a peak reverse voltage of 1200V and an average forward current of 50A, it is suitable for use in power supplies, motor drives, and other high-power equipment. The module's compact design and high surge current capability make it a versatile choice for various industrial applications.

• High Voltage Rating – Withstands up to 1200V peak reverse voltage.
• High Current Capacity – Supports up to 50A average forward current.
• Compact Design – Optimized for space-saving in equipment assemblies.
• High Surge Current Capability – Withstands non-repetitive peak forward surge currents up to 500A, suitable for applications with transient high-current demands.
• Low Forward Voltage Drop – Exhibits a forward voltage drop of 1.1V per diode at 25°C, enhancing efficiency.
• Isolated Baseplate – Provides electrical isolation between the chip and the baseplate, ensuring safety and reliability.
