HFA30PB120, Ultrafast Soft Recovery Diode, TO-247AC Package

The HFA30PB120 is an ultrafast soft recovery diode designed for high-voltage, high-power applications. With a peak reverse voltage of 1200V and a forward average current of 30A, it is suitable for use as a companion diode for IGBTs and MOSFETs in power supplies, inverters, motor drives, and other power conversion systems. The device features a low forward voltage drop, ultrafast soft recovery characteristics, and a glass-passivated junction for enhanced reliability. The TO-247AC package provides efficient thermal management and ease of integration into various designs.

• High Voltage Rating: Withstands a peak reverse voltage (V_R) of 1200V, suitable for high-voltage applications.
• High Forward Current: Capable of delivering a forward average current (I_F) of 30A, making it ideal for high-power applications.
• Ultrafast Soft Recovery: Features a typical reverse recovery time (t_rr) of 47 ns, reducing switching losses and electromagnetic interference (EMI).
• Low Forward Voltage Drop: Exhibits a forward voltage (V_F) of 2.4V at 30A, ensuring efficient operation with minimal power loss.
• Low Reverse Leakage Current: Demonstrates a reverse current (I_R) of 1.3 µA at 25°C, enhancing overall efficiency and reliability.
• TO-247AC Package: Offers efficient heat dissipation and ease of mounting in various applications.
