TIP127 ,PNP Silicon Transistor, TO-220-3, 100V, 5A High-Power Amplification

The TIP127 PNP Silicon Transistor is a powerful Darlington transistor designed for high-current, high-voltage applications. It features an integrated Darlington pair, which allows for a significantly higher current gain, making it suitable for applications that require efficient amplification and switching with minimal drive. Housed in a TO-220 package, this transistor supports easy mounting and excellent thermal performance, making it ideal for power circuits that handle significant heat dissipation.

With a collector-emitter voltage rating of 100V and a continuous collector current capacity of up to 5A, the TIP127 is well-suited for power amplification in audio circuits, motor drivers, and general-purpose low-speed switching applications. Its low saturation voltage ensures that power loss is minimized during switching operations, improving the overall efficiency of your circuit. Moreover, the device’s robust design allows it to handle a wide range of operating temperatures, making it suitable for both industrial and commercial applications.

Whether you’re designing audio amplifiers, switching regulators, or power control systems, the TIP127 transistor offers high reliability, ease of use, and dependable performance. Its ability to handle high power, coupled with low collector saturation, makes it an optimal choice for designers looking to optimize efficiency and performance in their systems.

• High Current Gain (hFE): The Darlington configuration provides a high current gain of 1000 at a 3A collector current, ensuring efficient amplification with minimal input.
• High Voltage Rating: Can handle up to 100V across the collector-emitter junction, making it suitable for high-voltage applications.
• High Current Capability: Supports a continuous collector current of up to 5A, ideal for high-power switching and amplification applications.
• Low Collector-Emitter Saturation Voltage: The low Vce(sat) of -2.0V at 3A reduces power loss, improving circuit efficiency during operation.
• Thermal Management: The TO-220-3 package allows for efficient heat dissipation, supporting up to 65W of power dissipation with proper heat sinking.
• Wide Temperature Range: Capable of operating in extreme conditions, with a temperature range of -65C to +150C, making it suitable for industrial applications.
