CD4060BM,14-Stage Binary Ripple Counter with Oscillator,SOIC-16

The CD4060BM is a high-performance CMOS 14-stage binary ripple counter featuring an integrated oscillator. It simplifies design for timing and frequency division applications by reducing external component requirements. The IC is designed to handle wide voltage ranges, operating from 3V to 15V, and supports clock frequencies up to 2 MHz.

Encased in a compact SOIC-16 package, the CD4060BM is ideal for surface-mount PCB layouts, ensuring efficient use of board space. Its low power consumption and asynchronous reset functionality make it a versatile solution for digital timing, frequency generation, and division in industrial and consumer applications.

• Integrated Oscillator Circuit: Eliminates the need for external oscillator components, simplifying timing applications.
• 14-Stage Ripple Counter: Accurately processes binary signals for frequency division and counting.
• Wide Operating Voltage Range: Compatible with CMOS and TTL logic levels, operates from 3V to 15V.
• Compact SOIC-16 Package: Space-saving surface-mount design for modern PCB layouts.
• High-Speed Operation: Capable of operating at clock frequencies up to 2 MHz at 15V.
• Asynchronous Master Reset: Provides rapid initialization of all counter stages.
