L9110H,Motor Driver IC,DIP-8

The L9110H is a dual-channel motor driver IC designed for DC and stepper motor control. This versatile IC integrates a push-pull power amplifier circuit, delivering high efficiency and reliability in motor driving applications. With its wide supply voltage range of 2.5V-12V and robust output capabilities, the L9110H is ideal for toy cars, robotIcs, and other motor control solutions.

This IC features low output saturation voltage, built-in clamp diodes for inductive loads, and high resistance to external interference. Its compact DIP8 package facilitates seamless integration into a wide range of electronic circuits. TTL/CMOS compatibility ensures easy interfacing with microcontrollers and processors, making the L9110H an essential component in modern motor control designs.

The L9110H supports continuous output currents of 800mA per channel and peak currents up to 2A, ensuring reliable performance under demanding conditions. It includes a high-voltage pin protection function and operates across a temperature range of 0°C to 80°C.

• Wide Voltage Range: Operates between 2.5V and 12V for versatile applications.
• Dual-Channel Output: Capable of driving two independent motors with forward and reverse motion.
• High Current Capability: Provides up to 800mA continuous current per channel, with a peak of 1.5A-2A.
• Low Quiescent Current: Ensures efficient power usage during idle states.
• Built-in Clamp Diodes: Protects against inductive load impact, enhancing circuit reliability.
• Compact DIP8 Package: Simple integration into various electronic projects.
