PS219C4-AST Intelligent Power Module 600V 15A DIP Mitsubishi

The PS219C4-AST from Mitsubishi Electric is a highly integrated Intelligent Power Module (IPM) designed to simplify motor control solutions by combining a 3-phase inverter bridge with gate drivers, bootstrap diodes, and multiple protection functions into a single compact DIP package. Optimized for low- to mid-power applications such as fans, pumps, and small compressors, the module supports up to 600V collector-emitter voltage and 15A output current, making it ideal for AC motor drives operating at 100–240VAC.

Key Features:

• 600V / 15A IGBT-based 3-phase inverter bridge
• Built-in under-voltage, short circuit, and over-temperature protection
• CSTBT™ 6th generation IGBT technology
• Integrated drive ICs and bootstrap diodes
• Long pin DIP package for through-hole mounting
• High isolation voltage: 1500Vrms (1 min)

Additional Specifications:

• Package Type: DIP
• Supply Voltage: 600V
• Current: 15A
• Type: Power Module (IPM) with integrated 3-phase inverter bridge and protection features
