PC929,High-Speed Optocoupler with IGBT Protector Circuit,SMD-14,4000V

The TLP3052 is a high-performance optoisolator triac driver designed to provide effective AC load switching with minimal noise. It features a gallium arsenide infrared LED optically coupled to a phototriac in a compact DIP-5 package. This optoisolator is optimized for applications such as motor control, lighting dimming, and static relays.

With a 600V off-state voltage rating and excellent dv/dt immunity, the TLP3052 ensures reliable performance even in electrically noisy environments. The device requires only a 10mA LED trigger current, making it energy-efficient for modern applications. It also provides an isolation voltage of 5000 Vrms, ensuring robust electrical isolation for safer operation.

Certified for UL standards and other international safety requirements, the TLP3052 delivers dependable and consistent performance in industrial and consumer applications.

• High Voltage Capability - Rated for 600V repetitive off-state voltage (VDRM).
• Compact DIP-5 Package - Ensures space-efficient integration in PCB designs.
• High Isolation Voltage - Withstands up to 5000 Vrms for enhanced safety and reliability.
• Low LED Trigger Current - Requires a maximum LED trigger current of 10mA, improving energy efficiency.
• Noise-Immune Operation - Offers high dv/dt immunity, ensuring stable performance in noisy environments.
• Versatile Applications - Ideal for motor controls, light dimmers, and static relays.
