TLP250,Optocoupler,8-Pin DIP

The TLP781 Optocoupler is a high-performance photocoupler featuring a gallium arsenide infrared emitting diode optically coupled to a silicon phototransistor. This configuration ensures high reliability and exceptional performance, making it suitable for a wide range of applications, including signal isolation, switching power supplies, and industrial controls. Its compact DIP-4 package allows for efficient use in space-constrained designs, while its high isolation voltage rating of 5000 Vrms enhances safety and reliability.

With a current transfer ratio ranging from 50% to 600% and a wide operating temperature range, the TLP781 is designed for robust performance under demanding conditions. Whether used in consumer electronics, office automation, or industrial applications, the TLP781 delivers consistent and dependable results.

• Compact DIP-4 Package: Easy integration with standard PCB designs.
• High Isolation Voltage: Ensures reliable electrical isolation up to 5000 Vrms.
• Wide Current Transfer Ratio (CTR): Operates efficiently within a range of 50% to 600%.
• Phototransistor Output: Suitable for low-power control circuits.
• Temperature Resilience: Operates reliably from -55C to +110C, accommodating extreme environments.
• Versatile Applications: Ideal for office equipment, solid-state relays, switching power supplies, and more.
