DBL494, PWM Controller IC, DIP-16

The DBL494 is a high-performance PWM Controller IC designed for power regulation and efficiency optimization in switching power supplies, DC-DC converters, and motor control applications. This IC integrates a precision oscillator, two error amplifiers, a dead-time control function, and output transistors, making it a complete power management solution.

With a wide operating voltage range of 7V to 40V, the DBL494 supports various power electronics applications, allowing for stable and efficient power conversion. The low power consumption of 10mA ensures minimal energy waste, making it ideal for energy-sensitive designs.

Packaged in a DIP-16 format, this IC is easy to integrate into through-hole PCB layouts, ensuring seamless development and production implementation. Its adjustable dead-time control enhances switching safety, reducing power loss in high-efficiency applications.

• Pulse Width Modulation (PWM) Control: Provides precise power regulation for switching power supplies and motor control applications.
• Wide Supply Voltage Range: Operates efficiently between 7V to 40V, making it versatile for various power circuits.
• Low Power Consumption: Operates with a typical supply current of 10mA, improving efficiency.
• Adjustable Dead-Time Control: Prevents switch overlap, reducing power loss and improving safety.
• DIP-16 Package for Easy Integration: Through-hole design allows for reliable PCB mounting and prototyping.
• Optimized for Power Management Applications: Ideal for DC-DC converters, motor speed control, and industrial power regulation.
