CNY17-3-DIP Optocoupler, Phototransistor Output,70V 50mA

The MOC3020-DIP Optocoupler is a high-performance component designed to provide safe and reliable isolation in high-voltage applications. Featuring a triac driver output and a 5000 Vrms isolation voltage, it ensures secure and efficient data transfer between circuits while protecting sensitive components.

Its DIP-6 package makes it ideal for easy PCB integration, and its ability to handle off-state terminal voltages of up to 400V enables it to support a wide range of applications, from motor control systems to solid-state relays. The optocoupler is UL and CSA certified, ensuring compliance with international safety standards.

With low forward voltage and high critical rise of off-state voltage (100 V/μs minimum), the MOC3020-DIP is suitable for efficient energy usage and precise triggering of thyristors and triacs. Whether used in household equipment or industrial automation, this optocoupler guarantees long-lasting and dependable performance.

• High Isolation Voltage: Provides 5000 Vrms isolation between input and output, ensuring safety in high-voltage systems.
• Triac Driver Output: Designed for reliable triggering of high-power thyristors and triacs.
• Durable Package Design: Compact DIP-6 package for easy integration into PCBs.
• Wide Voltage Handling: Supports an off-state terminal voltage (VDRM) of up to 400V.
• Efficient Triggering: Features a low forward voltage (Vf) of 1.15V (typical) for energy-efficient operation.
• Wide Operating Temperature: Operates reliably between -40C and +100C, suitable for demanding environments.
