CNY17,Optocoupler, Phototransistor Output,DIP-6

The MOC3081-DIP is an optocoupler featuring a gallium arsenide LED optically coupled to a zero-crossing bilateral triac driver. Designed for efficient control of AC loads, the device provides isolation between low-voltage logic inputs and high-voltage AC outputs. With high noise immunity and low trigger current requirements, it simplifies design in applications such as industrial motor control, lighting control, and consumer appliances.

Encased in a DIP-6 package, the MOC3081-DIP ensures reliable performance with high isolation voltage and robust dv/dt ratings, making it suitable for demanding environments.

• Zero-Crossing Circuitry: Provides smooth triac triggering at zero voltage for reduced noise and improved efficiency.
• High Isolation Voltage: 7,500 Vrms ensures safe operation in high-voltage applications.
• Wide Operating Voltage: Supports AC loads up to 240V with reliable triac driving capabilities.
• Compact DIP-6 Package: Designed for through-hole PCB mounting.
• Low LED Trigger Current: Operates with an input trigger current as low as 15 mA.
• dv/dt Robustness: Guaranteed 600 V/us, with typical performance at 1500 V/us.
