TIL193A Optocoupler Phototransistor Output DIP-6 High Isolation Voltage 60V Vceo 50mA Ic

The TIL193A is a single-channel phototransistor-output optocoupler designed for electrical isolation in control and signal circuits. It contains an infrared LED optically coupled to a silicon NPN phototransistor, allowing input and output to remain electrically isolated while transferring analog or digital signals.

Key Features:

• Phototransistor output optocoupler for signal isolation
• High collector-emitter voltage: 60V
• Maximum collector current: 50 mA
• 1-channel isolation device
• DIP-6 package for through-hole mounting
• High isolation voltage: 5300 Vrms

Additional Specifications:

• Package Type: DIP-16
• Collecter Emmiter Voltage Output (VCEO): 60V
• Maximum Collector Current (Ic): 50 mA
• Number of Channels: 1
• Mounting Style: Through-Hole
• Isolation Voltage: 5300 Vrms
• Forward Voltage (Vf): 1.25V
• Forward Current (If): 10 mA
