CD74HC22106E-DIP Dual Monostable Multivibrator, High-Speed Signal Processing, Reliable Integrated Circuit for Precision Timing

The CD74HC22106E-DIP is a versatile 8x8x1 crosspoint switch with memory control, designed using high-speed CMOS technology for precision timing and signal processing applications. Encapsulated in a 28-pin Dual In-line Package (DIP) for easy through-hole mounting, this integrated circuit is capable of switching 64 analog signals in a compact and efficient manner. The device features on-chip line decoding and control latches, allowing seamless operation and flexibility in switching configurations. It is engineered to operate over a wide voltage range of 2V to 10V, making it suitable for a variety of applications requiring robust signal management.

The CD74HC22106E also includes an automatic power-up reset feature and supports low "On" resistance for minimal signal loss, providing reliability in performance. With high noise immunity and the ability to cascade for matrix expansion in both X and Y directions, this crosspoint switch is ideal for use in audio, video, instrumentation, and other high-speed analog signal routing applications.

• 64 Analog Switches in an 8x8x1 Array: Offers a high-density configuration for managing multiple signal paths, ideal for complex routing and switching applications.
• On-Chip Line Decoder and Control Latches: Provides efficient control over signal routing, ensuring reliable switching operations with minimal external components.
• Wide Operating Voltage Range (2V to 10V): Compatible with various power supplies, making it versatile for use in different electronic systems and applications
.
• Low "On" Resistance (RON): Features a low resistance of 95ohm at VCC = 4.5V, minimizing signal loss and ensuring high-quality signal transmission.
• Automatic Power-Up Reset: Includes a power-up reset function utilizing a 0.1µF capacitor at the MR pin, ensuring all switches reset to a known state during power-up for consistent performance.
• High Noise Immunity: Offers noise immunity with N_L = 30%, N_H = 30% of VDD at both 5V and 10V, allowing stable operation in noisy environments.
