Ni15-G30-Y1 Proximity Switch Sensor

SKU
STSx0103
Brand:
In stock
Only 6 left

Guarantee safe & secure checkout

The proximity switch is a device designed for sensing the presence of objects near it. It features a threaded barrel with a size of M30 x 1.5 and is made of chrome-plated brass. It has a DC 2-wire output with a nominal voltage of 8.2 VDC and is capable of outputting according to the NAMUR standard (DIN EN 60947-5-6). The switch is connected via a cable and is approved for use in hazardous environments with ATEX category II 1G and II 1D certifications for Ex zones 0 and 20 respectively. It also has SIL2 (Low Demand Mode) and SIL3 (All Demand Mode) certifications according to IEC 61508 and ISO 13849-1 with redundant configuration HFT1.

Features:

Threaded barrel with size M30 x 1.5
Made of chrome-plated brass
DC 2-wire output, nominal voltage of 8.2 VDC
NAMUR standard (DIN EN 60947-5-6) output
Cable connection
ATEX category II 1G, Ex zone 0 and ATEX category II 1D, Ex zone 20 approvals
SIL2 (Low Demand Mode) and SIL3 (All Demand Mode) certifications
Non-flush mounting conditions
Switching frequency of 0.20 kHz
Cable length of 2.0 m
Housing material: metal, CuZn, chrome-plated
Ambient temperature range of -25 to 70 °C
IP67 protection class
Approvals: ATEX II 1G, ATEX II 2G, ATEX II 3G, ATEX II 1D, ATEX II 2D, ATEX II 3D, SIL2, PLc



More Information
Brand Truck
Sensor Type Proximity Switch Sensor
Current Consumption N/A
Communication Interface N
