● Display 4000 counts
● Jaw Opening Ф42mm/1.7"
● Auto and Manual ranging
● Auto Power Off
● Diode Open Voltage 2.2V
● Continuity Buzzer <50±20Ω
● Data Hold
● Low Battery Display

General:

● Power Supply : 1×9V 6F22 Battery
● Product Size : 250mm×99mm×43mm/9.8"×3.9"×1.7"
● Product Weight : 416g/0.92lb
● Certification : RoHS
● Safety Rating : CAT II 1000V / CAT III 600V

Specifications:

DC Voltage Range: 400mV/4V/40V/400V/1000V
Resolution: 0.1mV/1mV/10mV/0.1V/1V
Accuracy: ±(0.7% 1) / ±(0.8% 3)
AC Voltage Range: 4V/40V/400V/750V
Resolution: 1mV/10mV/0.1V/1V
Accuracy: ±(0.8% 5) / ±(1.0% 10)
DC Current Range: 400A/1000A
Resolution: 0.1A/1A
Accuracy: ±(3.0% 3)
AC Current Range: 400A/1000A
Resolution: 0.1A/1A
Accuracy: ±(3.0% 3)
Resistance Range: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
Resolution: 0.1Ω/1Ω/10Ω/0.1kΩ/1kΩ/10kΩ
Accuracy: ±(1.2% 1) / ±(2.0% 3)
Capacitance Range: 4nF/40nF/400nF/4µF/40µF/100µF
Resolution: 1pF/10pF/0.1nF/1nF/10nF/100nF
Accuracy: ±(4.0% 10)
Frequency Range: 40Hz/400Hz/4kHz/40kHz/100kHz
Resolution: 0.01Hz/0.1Hz/1Hz/10Hz/0.1kHz
Accuracy: ±(2.0% 1)
Duty Cycle Range: 0.1%~99.9%
Resolution: 0.10%
Accuracy: ±(2.0% 2)
Temperature Range: -40℃-0℃/1℃-400℃/401℃~750℃
Resolution: 1℃
Accuracy: ±(1.0% 6) / ±(1.0% 3) / ±(1.0% 5)
