Description :

-The capacitive fingerprint sensor supports various functions such as fingerprint capture, image processing, fingerprint storage, and fingerprint comparison
-It uses ID809 high-performance processor and semiconductor fingerprint sensor as the core
-Built-in IDfinger6.0 algorithm allows it to complete all fingerprint identification work independently
-UART communication is supported, and it can be easily integrated with Arduino library to enable functions like fingerprint registration and deletion
-The sensor has a round breathing LED, a simple structure, a small size and a delicate appearance
-Offers fast recognition speed, high security and supports 360-degree arbitrary angle recognition and deep self-learning function
-High performance and low power consumption.

-Features:

•360-degree fingerprint entry and matching
•Self-learning function
•CNC metal ring, plus aperture
-Applications:
•Fingerprint door-lock
•Drawer Lock
•Identity Recognition
•Authorization
-Specifications:
•Operating Voltage: 3.3V
•Operating Current: <60mA
•Communication Method: UART
•Storage Capacity: 80 fingerprints
•1 : 1 verification time: 300~400ms
•Pixel Resolution: 508dpi
•Number of Pixels: 160x160
•Fingerprint Detection Area: 8.0mm x 8.0mm
•Working Environment: ‐40‐60℃/
•Dimension: diameter 21mm/height 5mm
