Specifications:

Number of Circuits: 1
Logic Family: HC
Logic Type: D-Type Edge Triggered Flip-Flop
Polarity: Inverting
Input Type: Single-Ended
Output Type: Single-Ended
Propagation Delay Time: 14 ns at 5 V
High Level Output Current: - 7.8 mA
Low Level Output Current: 7.8 mA
Supply Voltage - Min: 2 V
Supply Voltage - Max: 6 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: 125 C
Mounting Style: Through Hole
Package/Case: DIP-20
Function: D-Type Bus Interface
Height: 3.2 mm
Length: 26.92 mm
Number of Channels: 8
Number of Input Lines: 8
Number of Output Lines: 8
Operating Supply Voltage: 5 V
Product Type: Flip Flops
Quiescent Current: 8 uA
Width: 6.4 mm
Unit Weight: 2,509 g
