74HC07D SOP-14

SKU
SCIx4300
Brand:
Categories:
In stock
Add to Wish List

Guarantee safe & secure checkout

"The M74HC07 is a high speed CMOS HEX OPEN DRAIN BUFFER fabricated with silicon gate C2MOS technology.
The internal circuit is composed of 2 stages including buffer output, which enables high noise immunity and stable output.
All inputs are equipped with protection circuits against static discharge and transient excess voltage.



â–  HIGH SPEED: tPD = 6ns (TYP.) at VCC = 6V
â–  LOW POWER DISSIPATION: ICC = 1µA(MAX.) at TA=25°C
â–  HIGH NOISE IMMUNITY: VNIH = VNIL = 28 % VCC (MIN.)
â–  WIDE OPERATING VOLTAGE RANGE: VCC (OPR) = 2V to 6V
â–  PIN AND FUNCTION COMPATIBLE WITH 74 SERIES 07
