H3YN-2, Multifunction Timer Relay, 24VAC, 1S–10M, DPDT, Plug-in

The Omron H3YN-2 Multifunction Timer Relay is a versatile timing solution supporting four timing ranges from 1 second to 10 minutes. It runs on 24VAC and features a reliable DPDT output. With a plug-in base and mechanical dial, it provides quick setup and long operational life for use in industrial control panels, automation systems, and time-delay operations.

Key Features:

• Multiple timing ranges: 1 sec, 10 sec, 1 min, 10 min
• Operates on 24VAC at 50/60Hz
• High-precision analog dial with wide adjustability
• Compact DPDT configuration for versatile applications
• Designed for easy DIN rail or panel mounting
• Ideal for industrial automation and control systems

Additional Specifications:

• Type: Analog Timer
• Operating Supply Voltage: 24Vac At 50-60Hz
• Timing Range: 1S,10S,1Min,10Min
• Display Type: Mechanical Dial
• Accuracy: ±1%
