SSR-25DD, Solid State Relay, Panel Mount

The SSR-25DD is a DC-controlled solid state relay engineered for switching DC loads up to 25A. With an input control voltage range of 3–32VDC and load-side capability up to 120VDC, it's ideal for motor control, LED lighting systems, and DC heating elements. Its opto-isolated trigger design ensures safe and reliable operation in industrial environments.

Key Features:

• DC-to-DC Operation: Ideal for switching DC loads with a DC control signal
• High Load Handling: Supports up to 25A switching current
• Optical Isolation: Protects control circuitry from load-side interference
• Compact and Rugged: Space-saving for panel installations in harsh environments
• Fast Response Time: Perfect for applications requiring frequent switching
• No Mechanical Wear: Fully electronic design ensures silent, long-lasting performance

Additional Specifications:

• Type: Solid State Relay
• Number of Channels: 1
• Coil Voltage: 3-32Vdc
• Switching Voltage (VDC)/Current: 5-120Vdc At 25A
• Switching Voltage (VAC)/Current: N/A
