JQ1P-24V-F, General-Purpose Relay, Through-Hole Mount

The Panasonic JQ1P-24V-F is a high-capacity, general-purpose relay featuring a 24VDC coil and SPDT contact configuration. Its compact design and robust performance make it ideal for a wide range of applications, including industrial automation, HVAC systems, and power control circuits. The relay's high switching capacity and high electrical noise immunity ensure reliable operation in demanding environments.​

Key Features:

• High Switching Capacity: Handles up to 10A at 250VAC or 5A at 30VDC, suitable for various applications​
• SPDT Contact Configuration: Single-pole, double-throw (1 Form C) for versatile control​
• Compact Design: Space-saving form factor ideal for PCB integration​
• High Electrical Noise Immunity: Ensures reliable operation in electrically noisy environments​
• Wide Operating Temperature Range: Operates reliably from -40°C to +70°C​
• UL, CSA, VDE, SEMKO Approved: Meets international safety and performance standards​

Additional Specifications:

• Type: Electromechanical Relay​
• Number of Channels: 1
• Coil Voltage: 24Vdc
• Switching Voltage (VDC)/Current: 30Vdc At 5A
• Switching Voltage (VAC)/Current: 250Vac At 10A
