IRF3307, N-Channel Power MOSFET, TO-220

The IRF3307 is a rugged N-channel enhancement-mode Power MOSFET designed for ultra-low on-resistance and fast switching performance. It is ideal for use in DC-DC converters, low-voltage power tools, synchronous rectification, motor drives, and high-efficiency switching circuits. Its compact TO-220 package and high power dissipation make it well-suited for compact power designs.

Key Features:

• Ultra-Low R_DS(on): Only 0.009 Ω, maximizing conduction efficiency.
• High Current Capability: Supports up to 74 A continuous drain current.
• High-Speed Switching: Low gate charge of 64 nC enables fast transitions.
• Rugged Avalanche Performance: Excellent single-pulse avalanche energy rating.
• Standard Gate Drive: V_GS(th) typical at 2.0 – 4.0 V.
• Reliable TO-220 Package: Suitable for high-density, thermally constrained environments.

Additional Specifications:

• Mounting Style: Through Hole
• Continuous Current Drain (Id): 74A
• Drain-Source Breakdown Voltage (Vds): 30V
• Gate-Source Threshld Voltage (Vgs th): 2-4V
• Power Dissipation: 120W
• Operating Temprature: -55+175°C
