RHRG75120, Hyperfast Rectifier Diode, TO-247

The RHRG75120 is a high-performance 1200V, 75A Hyperfast Rectifier Diode, designed for freewheeling, clamping, and rectification applications in switching power supplies, motor control systems, and high-frequency power circuits. Its low forward voltage drop (2.4V at 75A) helps minimize conduction losses, enhancing system efficiency.

With a maximum surge current rating of 400A, this diode provides excellent transient protection in power electronics. The low reverse leakage current (200µA at 1200V) ensures stable operation and minimal energy dissipation in high-voltage environments.

Encased in a TO-247 package, the RHRG75120 offers superior thermal performance and ease of integration into high-power electronic systems. Its wide operating temperature range (-55°C to +175°C) makes it suitable for use in industrial automation, motor drives, and renewable energy applications.

• High Voltage Rating: Supports a maximum peak reverse voltage (VRRM) of 1200V, ensuring reliable performance in high-voltage circuits.
• High Current Handling: Rated for a forward average current (If) of 75A, making it suitable for power rectification.
• Ultra-Low Forward Voltage Drop: Operates with a forward voltage (Vf) of 2.4V at 75A, reducing conduction losses.
• High Surge Capability: Withstands 400A non-repetitive surge current (ITSM) at 60Hz, protecting against transient spikes.
• Low Reverse Leakage Current: Ensures minimal power loss with a maximum reverse current (Ir) of 200µA at 1200V.
• Wide Operating Temperature Range: Designed to function between -55°C to +175°C, making it ideal for demanding industrial applications.
