TIP141,NPN Power Transistor,TO-247

The TIP141 is a high-performance NPN power transistor designed for applications requiring efficient switching and amplification. With a maximum collector-emitter voltage of 80V and a continuous collector current of 10A, this transistor ensures reliable performance in power amplifiers, industrial motor controllers, and switching circuits.

Encased in a TO-247 package, the TIP141 provides efficient thermal dissipation, making it suitable for heavy-duty electronic applications. Its high current gain (hFE) up to 1000 ensures minimal power loss while maintaining excellent switching performance.

With a power dissipation of 125W and a wide operating temperature range of -65°C to +150°C, the TIP141 is a reliable choice for industrial and consumer applications. Whether used in high-power audio amplifiers or industrial control systems, this transistor delivers long
Key Features:

• High Voltage and Current Handling: Withstands up to 80V collector-emitter voltage (VCEO) and delivers a continuous collector current (Ic) of 10A, suitable for high-power applications.
• Exceptional Current Gain: High DC current gain (hFE) of 1000 ensures efficient operation in amplifier and switching circuits.
• High Power Dissipation: Supports power dissipation of up to 125W, ensuring reliable performance under heavy loads.
• Robust Construction: Encased in a TO-247 package for excellent thermal management and durability.
• Wide Operating Temperature Range: Operates effectively between -65°C and +150°C, suitable for industrial and consumer environments.
• Low Saturation Voltage: Reduces power losses, enhancing overall circuit efficiency.
