TD6111P, Frequency Prescaler IC, SIP-7 Package

The TD6111P is a compact, high-speed logic IC used primarily in frequency division applications. Housed in a 7-pin SIP (Single In-line Package), it is ideal for frequency counters, signal conditioning, or prescaler stages in RF circuits. With a nominal supply voltage of 5V and a wide terminal pitch of 2.54 mm, it is easy to integrate into standard PCBs. Its small footprint and reliability make it suitable for commercial communication and signal processing equipment.

Key Features:

• Integrated Frequency Divider: Designed for single high-speed prescaler function.
• Standard TTL-Compatible Supply: Operates with 5V typical logic voltage.
• Compact SIP Package: Single in-line package makes it space-efficient and easy to mount.
• Commercial Grade Temperature Range: Operates from -10°C to +65°C for general-purpose environments.
• Low Power Design: Ideal for integration into digital frequency counters or communication systems.
• Toshiba Quality: Developed by Toshiba America Electronic Components for reliable RF logic processing.

Additional Specifications:

• Package Type: SIP
• IC type: Logic IC
• Mounting Style: Through Hole
