2SC1983, NPN Silicon Darlington Transistor, TO-220 Package

The 2SC1983 is an NPN silicon Darlington transistor housed in a TO-220 package. It is designed for switching regulators, pulse-width modulation (PWM) inverters, and solenoid and relay drivers. The transistor offers a high DC current gain with a minimum h_FE of 500, ensuring strong signal amplification. It supports a collector current of up to 3 A and a collector-emitter voltage of 60 V, making it suitable for medium power applications. The device features low saturation voltage, ensuring efficient performance with minimal power loss. Its fast switching capabilities make it ideal for high-speed switching applications. Encased in a standard TO-220 package, the 2SC1983 provides efficient heat dissipation and ease of mounting.

• High DC Current Gain: Minimum h_FE of 500, providing strong amplification.
• High Collector Current: Supports up to 3 A, suitable for medium power applications.
• High Collector-Emitter Voltage: Rated at 60 V, enabling operation in moderate voltage circuits.
• Low Saturation Voltage: Ensures efficient performance with minimal voltage drop.
• Fast Switching Speeds: Ideal for high-speed switching applications.
• Standard TO-220 Package: Facilitates easy mounting and efficient heat dissipation.
