HM6116LP-3 High-Speed CMOS Static RAM (DIP-24)

The HM6116LP is a 16,384-bit high-speed static random-access memory (SRAM) fabricated using advanced CMOS technology. It is organized as 2K x 8 bits, making it an ideal choice for 8-bit microprocessor systems requiring a compact and reliable memory solution. The "LP" designation indicates a low-power version, specifically designed for applications where power conservation is critical, such as battery-backed data retention circuits. Because it is a static RAM, it eliminates the complexity of refresh cycles associated with dynamic RAM, simplifying the overall system design. The device is housed in a standard 24-pin dual in-line package (DIP-24), providing a familiar and robust footprint for industrial controllers, legacy computing systems, and embedded instrumentation.

Key Features:

Features low power consumption with a typical standby current of 5 microamps.

Fast access time of 120 to 150 nanoseconds for high-speed data retrieval.

Fully static operation requiring no external clock or refreshing signals.

Single 5V power supply operation with a tolerance of plus or minus 10 percent.

Directly compatible with standard TTL logic levels for all inputs and outputs.
