4N45,High-Gain Darlington Output Optocoupler,DIP-6

The PC923 Optocoupler is a high-speed photocoupler designed specifically for MOSFET and IGBT drive applications. This optocoupler provides effective isolation between input and output circuits, making it ideal for noise-sensitive environments and applications where safety isolation is required. With an isolation voltage of 5kV, the PC923 offers robust protection and ensures reliable signal transfer without electrical interference.

Housed in a compact DIP package, the PC923 features a single-channel configuration that supports high-speed operation and efficient signal transmission. The component’s collector-emitter voltage (VCEO) and maximum collector current (Ic) specifications make it suitable for a range of industrial and power control applications. Its surface-mount style allows for easy integration onto printed circuit boards (PCBs) while maintaining a small footprint.

The PC923 Optocoupler is ideal for engineers and DIY enthusiasts working on power management, motor control, and signal isolation projects, ensuring stable and interference-free performance.

• High Isolation Voltage: 5kV isolation for secure signal transfer.
• Single-Channel Configuration: Supports precise signal transmission in compact designs.
• High-Speed Performance: Suitable for MOSFET and IGBT drive applications.
• Compact DIP Package: Saves space on PCBs for efficient design.
• Reliable Operation: Designed to maintain stability in noise-sensitive environments.
• Efficient Power Usage: Optimized forward current (If) and forward voltage (Vf) for energy-efficient operation.
