HCNR200,High-Linearity Analog Optocoupler,DIP-8

The PS2501-4 Optocoupler is a high-performance signal isolator designed for a wide range of applications, including industrial controls, telecommunications, and power supply circuits. This device features four optocoupler channels, each consisting of a gallium arsenide infrared light-emitting diode optically coupled to an NPN silicon phototransistor.

Encased in a compact DIP-16 package, the PS2501-4 supports through-hole mounting for easy and secure installation. With an isolation voltage of up to 5000Vrms, it ensures safe and reliable signal transmission across electrically isolated circuits. The device is rated for 80V collector-emitter voltage and 50mA collector current, making it ideal for high-voltage and high-current applications. Its forward voltage of 1.4V and forward current of 80mA provide energy-efficient and fast-switching performance.

Whether you're designing industrial control panels or building telecommunications systems, the PS2501-4 Optocoupler delivers consistent and dependable results for all your electronic needs.

• High Isolation Voltage: Provides electrical isolation up to 5000Vrms, ensuring reliable and safe signal transmission.
• Compact DIP-16 Package: Designed for efficient through-hole mounting and easy integration into electronic systems.
• Multiple Channels: Features 4 optocoupler channels for isolating and transmitting multiple signals.
• High Voltage and Current Ratings: Supports 80V collector-emitter voltage (VCEO) and 50mA collector current (Ic).
• Wide Application: Suitable for power supplies, industrial controls, and telecommunications equipment.
• Reliable Performance: Built for high-speed switching with a forward voltage (Vf) of 1.4V and forward current (If) of 80mA.
