TLP291,Optocoupler,GaAs IRED & Photo-Transistor Output,DIP-4

The CNY74-4 is a versatile quad-channel optocoupler designed to provide exceptional signal isolation and protection in high-voltage circuits. Featuring four independent optocouplers within a single DIP-16 package, this component is ideal for galvanic isolation and non-interacting switching applications. With a high collector-emitter voltage of 70V and a robust 2.5kV DC isolation voltage, the CNY74-4 offers reliable performance in demanding environments.

Designed for ease of use and reliability, the CNY74-4 operates within a wide temperature range of -40C to +100C. Its low coupling capacitance and high current transfer ratio ensure efficient operation with minimal signal interference. Whether used in industrial control systems, power supplies, or signal isolation circuits, the CNY74-4 delivers consistent and dependable results.

• High Current Transfer Ratio: Offers a typical current transfer ratio (CTR) of 160% to 320%, ensuring efficient signal transfer.
• Robust Isolation Voltage: Provides a 5kV isolation voltage for safe and reliable operation in high-voltage environments.
• Compact DIP-6 Package: Designed for ease of integration into compact PCB designs.
• Versatile Applications: Ideal for signal isolation, switching applications, and galvanic isolation.
• Wide Operating Temperature Range: Functions reliably from -55C to 100C, suitable for demanding applications.
• Low Coupling Capacitance: Reduces signal interference with a low coupling capacitance of 0.3 pF.
