CD4026BE,Decade Counter with 7-Segment Display Driver,DIP-16

The CD4026BE is a high-performance decade counter with an integrated 7-segment display driver. This versatile IC simplifies display applications by combining counting and display-driving functions in a single device. The compact DIP-16 package makes it ideal for through-hole PCB designs, ensuring straightforward integration into various projects.

With a wide operating voltage range from 3V to 18V, the CD4026BE offers compatibility with both CMOS and TTL logic families. Its high-speed operation, supporting frequencies up to 6 MHz, makes it suitable for digital clocks, counters, and display applications in consumer, industrial, and educational designs.

• Integrated Display Driver: Directly drives 7-segment displays for simplified circuit designs.
• Wide Voltage Range: Operates from 3V to 18V, compatible with CMOS and TTL logic levels.
• High-Speed Operation: Supports frequencies up to 6 MHz at 10V.
• Reset Functionality: Includes asynchronous clear for resetting counter states.
• Compact DIP-16 Package: Easy-to-use through-hole design for prototyping and production.
• Versatile Applications: Ideal for counters, clocks, and digital displays.
