29LV160TE-70PF, 16-Mbit Parallel NOR Flash Memory, Top Boot Block, TSOP-48 Package Type

The 29LV160TE-70PF is a 16-megabit top boot NOR flash memory IC manufactured by Macronix (and previously also by SST/Fujitsu-compatible designs). It supports both byte-wide (x8) and word-wide (x16) access modes and is designed for code storage in embedded systems, such as consumer electronics, industrial equipment, and telecommunications devices.

Key Features:

• 16 Mbit (2M x 8-bit / 1M x 16-bit) Flash memory
• Top Boot Block architecture
• Fast access time: 70 ns
• Single 3.0V supply for read, erase, and program
• 100,000 program/erase cycles with 20-year data retention
• Supports both 8-bit and 16-bit bus modes

Additional Specifications:

• Memory Type: NOR Flash Memory
• Interface Type: Parallel
• Supply Voltage: 2.7V to 3.6V
• Memory Size: 16 Mbit
