MCT2E,Optocoupler,DIP-6

The NEC 2561 Optocoupler is a versatile and reliable electronic component designed to provide electrical isolation and signal transmission in a wide range of applications. With a Collector-Emitter Voltage (VCEO) of 80V and a maximum collector current of 50mA, this optocoupler is well-suited for circuits that require safe signal transmission without direct electrical connection. Its SMD package allows for easy integration into space-sensitive designs, making it ideal for both consumer and industrial applications.

Featuring one channel, the NEC 2561 Optocoupler provides isolation between input and output, ensuring protection of low-voltage components in high-voltage environments. The optocoupler’s ability to operate in various conditions, with an operating temperature range from -55C to +100C, makes it perfect for demanding environments. Its high isolation voltage of 5000V ensures superior safety for electrical devices and systems, providing a long-lasting, dependable solution for signal transmission and isolation needs.

Use the NEC 2561 in motor control circuits, power supply units, or any application requiring high electrical isolation. This compact, robust optocoupler is an excellent choice for professionals and hobbyists working on projects that demand safe, isolated signal transmission.

• High Voltage Rating – The NEC 2561 offers a Collector-Emitter Voltage (VCEO) rating of 80V, ideal for circuits requiring reliable signal isolation.
• Compact Surface Mount Design – Featuring an SMD package, this optocoupler is perfect for modern, space-conscious PCB designs.
• Single Channel Design – Suitable for applications requiring isolation for a single signal, providing efficient electrical isolation and signal transmission.
• Low Power Consumption – The NEC 2561 operates efficiently with a maximum collector current of 50mA, reducing power draw in your circuits.
• Electrical Isolation – Provides up to 5000V isolation between input and output, making it ideal for high-voltage applications and protecting sensitive components.
• Versatile Application – Commonly used in industrial controls, consumer electronics, power supplies, and motor drivers, ensuring broad compatibility.
