SP5658F, Frequency Synthesizer, 2.7GHz, 3-Wire Bus Control ,SO-14

The SP5658F is a high-performance, single-chip frequency synthesizer specifically designed for tuning systems up to 2.7GHz. With a 3-wire bus control interface, it provides accurate and stable frequency generation, making it ideal for communication systems, SAT, TV, VCR, and cable tuning applications. The device includes two selectable prescaler options, enabling it to divide input frequencies up to 2GHz, which makes it highly adaptable for diverse application requirements.

The SP5658F features low phase noise, essential for high-clarity signal generation, and integrates a charge pump disable function for power-efficient operation. It is also equipped with a varactor line disable and an "in-lock" flag for additional control and status monitoring. Housed in a compact SMD package, the SP5658F ensures reliable operation with ESD protection compliant with MIL–STD 883 TM 3015, providing robust performance even in demanding environments.

Key Features :

• High Frequency Capability: Supports up to 2.7GHz tuning range for versatile communication applications.
• Selectable Prescaler: Configurable divide-by-two prescaler enables flexible frequency division.
• Low Phase Noise: Optimized design to minimize phase noise, enhancing signal clarity.
• Integrated Charge Pump Disable: Built-in charge pump disable function for controlled operation.
• Varactor Line Disable: Includes a varactor line disable feature to prevent unwanted frequency drifts.
• ESD Protection: Integrated ESD protection compliant with MIL–STD 883 TM 3015 standards for improved reliability in various environments.
