The PIC16F873-20/SP is an 8-bit microcontroller from Microchip Technology's PIC® 16F family, designed for a wide range of embedded applications. Operating at speeds up to 20MHz, it delivers efficient performance for various control and automation tasks.
Equipped with 7KB of Flash program memory, 192 bytes of RAM, and 128 bytes of EEPROM, the PIC16F873-20/SP offers sufficient storage for code and data. Its versatile connectivity options, including I²C, SPI, and UART/USART interfaces, enable seamless communication with other devices and peripherals.
The microcontroller integrates essential peripherals such as Brown-out Detect/Reset, Power-On Reset (POR), Pulse Width Modulation (PWM), and a Watchdog Timer (WDT), enhancing system reliability and control. The 10-bit, 5-channel Analog-to-Digital Converter (ADC) allows for accurate analog signal processing, making it suitable for sensor interfacing and measurement applications.
Housed in a 28-pin SPDIP package, the PIC16F873-20/SP is ideal for through-hole mounting, facilitating easy integration into various hardware designs.
Key Features :- High-Performance RISC CPU: Executes most instructions in a single cycle, enhancing processing efficiency.
- 7KB Flash Program Memory: Provides ample space for code storage with 4K x 14 words of Flash memory.
- Versatile Connectivity: Supports I²C, SPI, and UART/USART interfaces for flexible communication options.
- Integrated Peripherals: Includes Brown-out Detect/Reset, Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT) for robust system control.
- 10-Bit Analog-to-Digital Converter (ADC): Features a 5-channel ADC for precise analog signal conversion.
- In-Circuit Serial Programming (ICSP): Allows for programming and debugging directly within the application circuit.
