OPA660AP ,Wide Bandwidth Operational Transconductance Amplifier, 850MHz Bandwidth, 3000V/us Slew Rate

The OPA660 is a versatile monolithic component designed for wide-bandwidth systems, including high-performance video, RF, and IF circuitry. It features a voltage-controlled current source or Operational Transconductance Amplifier (OTA) with a low-impedance input, controlled current output, and a voltage buffer amplifier. With a wide 850MHz bandwidth and fast 3000V/us slew rate, the OPA660 is ideal for applications requiring high-speed signal processing.

The open-loop buffer amplifier also provides 850MHz bandwidth, making it suitable for demanding analog applications such as AGC amplifiers, LED drivers for fiber optic transmission, and high-speed data acquisition. This component's reliability and low power consumption make it a robust choice for a variety of RF, video, and audio applications.

Key Features :

• High Bandwidth: Operates at a wide bandwidth of 850MHz, suitable for high-frequency applications.
• High Slew Rate: Delivers a rapid response with a slew rate of 3000V/us, essential for high-speed data transmission.
• Low Differential Gain and Phase Error: Minimizes signal distortion with a low differential gain error of 0.06% and phase error of 0.02°, ensuring clear and accurate signal processing.
• Precision external IO control allowing customizable current output for fine-tuned performance across diverse applications.
• Versatile Circuit Function: Optimized for applications including AGC, multipliers, and integrators, making it highly adaptable in communication and broadcast equipment.
• Wide Temperature Range: Reliable performance over an extended operating temperature range of -40°C to +85°C, suited for various environmental conditions.
