LC7535, Electronic Volume Control IC, DIP-30

The LC7535 is a high-performance Electronic Volume Control IC designed for use in audio systems. It integrates volume, tone, and balance control capabilities into a single IC, providing precise and reliable audio adjustments. The serial data interface allows seamless integration with digital control systems, making it a versatile solution for modern audio equipment.

With its DIP-30 package, the LC7535 is easy to implement in through-hole PCB designs, enabling straightforward prototyping and production. Its wide operating voltage range ensures compatibility with a variety of system configurations, making it suitable for home audio systems, AV receivers, and professional sound equipment.

• Electronic Volume Control: Facilitates smooth and precise adjustment of audio volume levels.
• Tone and Balance Adjustment: Integrated functionality for fine-tuning audio tone and balance.
• Serial Data Interface: Simplifies control via microcontrollers or digital systems.
• Wide Operating Voltage Range: Supports a variety of audio system designs with flexible voltage requirements.
• Compact DIP-30 Package: Ensures ease of prototyping and integration into audio equipment.
• Reliable Performance: Designed for high-quality sound systems and professional audio applications.
