TLP521-3,Optocoupler,Triple-Channel Phototransistor Output,DIP-8

The H11L1 Optocoupler is a high-performance device designed for fast and reliable electrical isolation in digital circuits. It features a gallium arsenide infrared LED optically coupled to a high-speed integrated detector with a Schmitt trigger output. This combination ensures noise-free signal transmission and compatibility with TTL and CMOS logic circuits.

Encased in a compact DIP-6 package, the H11L1 optocoupler is perfect for applications such as motor control, power supply regulation, digital logic isolators, and microprocessor interfacing. With a high isolation voltage of 5300 Vrms and robust temperature performance, this optoisolator guarantees dependable operation in demanding environments.

• High-Speed Switching: Schmitt trigger output enables fast and noise-free signal isolation.
• High Isolation Voltage: Rated at 5300 Vrms for safe and reliable electrical separation.
• Wide Compatibility: Suitable for interfacing with TTL and CMOS logic circuits.
• Compact DIP-6 Package: Standard package for easy PCB integration.
• Wide Operating Temperature Range: Performs reliably in environments from -40C to +85C.
• Low Power Consumption: Designed to operate efficiently with minimal energy loss.
