BA6898S,4-Channel BTL Driver IC for CD Players,DIP-24

The BA6898S is a high-performance 4-channel BTL driver IC, engineered for optical disc applications like CD players and CD-ROM systems. Featuring a built-in adjustable gain, thermal protection, and a 5V regulator with external PNP transistor compatibility, this IC delivers outstanding performance and reliability. The integrated multi-purpose operational amplifier adds versatility for advanced circuit designs.

Designed for through-hole PCB assembly, the BA6898S comes in a DIP-24 package, simplifying integration into various projects. Its internal level shift circuit and reset output further reduce design complexity. With thermal shutdown protection and robust operational features, this IC ensures safe and efficient performance in various optical disc equipment applications.

• 4-Channel BTL Driver: Efficiently drives focus and tracking signals for CD players and CD-ROM systems.
• Adjustable Gain: Allows precise customization with an external resistor for optimal performance.
• Integrated 5V Regulator: Built-in regulator with external PNP transistor support ensures reliable operation.
• Thermal Protection: Includes a thermal shutdown circuit that activates at 175°C for safety and durability.
• Multipurpose Operational Amplifier: Designed for additional signal processing tasks within the same IC.
• Compact DIP-24 Package: Easy to integrate into through-hole PCB designs, saving space and simplifying assembly.
