AT25040N EEPROM Memory IC 4Kbit SPI Interface 8MHz Clock DIP-8 Low Voltage Operation

The AT25040N is a low-power, high-performance 4Kbit serial EEPROM organized as 512 bytes of 8 bits each. It supports SPI (Serial Peripheral Interface) protocol and allows both byte-level and page-level writes, making it ideal for applications requiring frequent data updates.

Key Features:

• 4Kbit (512 × 8) Serial EEPROM with SPI interface
• 1MHz to 10MHz clock rate depending on voltage
• Byte and Page Write capabilities (up to 16 bytes)
• Low power standby and active modes
• Data retention of over 100 years
• 1 million write/erase cycles minimum

Additional Specifications:

• Memory Type: EEPROM
• Interface Type: SPI
• Supply Voltage: 5.5V
• Memory Size: 4 Kbit
