CD4553BE Triple 3-Digit BCD Counter IC DIP-16 CMOS 5V to 15V Supply Low Power Consumption

The CD4553BE is a CMOS triple 4-bit binary counter designed for use in BCD (Binary Coded Decimal) display systems, timekeeping, event counting, and data acquisition systems. Each of its three stages can count up to 15 (4-bit binary), and together they form a complete 3-digit counter in one package.

Key Features:

• Triple 4-bit counter for 3-digit BCD applications
• Wide supply range: 3V to 15V (typically 5V or 10V)
• Fully static operation with low power consumption
• TTL-compatible inputs and outputs
• DIP-16 package with through-hole mounting
• Count enable, reset, and clock inputs for each stage

Additional Specifications:

• Package Type: DIP-16
• Type: Triple 4-bit BCD
• Timing Mode: Synchronous Counter with individual digit reset and count enable
• Supply Voltage: 15V
• Count Rate: 5 MHz
