CD4512BE, 8-Channel Data Selector/Multiplexer, DIP-16

The CD4512BE is a CMOS 8-channel data selector/multiplexer that selects one of eight binary inputs and routes it to a single output. It features a three-state output, allowing for direct interfacing with bus-oriented systems by enabling high-impedance states when the device is not in use. The device operates over a wide supply voltage range from 3V to 18V, making it versatile for various applications. Its standard CMOS compatibility ensures seamless integration into digital circuits. The CD4512BE is housed in a 16-pin Dual In-line Package (DIP), suitable for through-hole mounting.

• 8-Channel Data Selection: Selects one of eight data inputs for the output, facilitating efficient data routing.
• Three-State Output: Allows direct interfacing with bus-oriented systems by enabling high-impedance output states.
• Wide Supply Voltage Range: Operates from 3V to 18V, providing flexibility for various applications.
• Standard CMOS Compatibility: Compatible with CMOS logic levels, ensuring seamless integration into digital circuits.
• Low Power Consumption: Designed for energy-efficient operation in electronic systems.
• Through-Hole Mounting: Encased in a 16-pin Dual In-line Package (DIP), suitable for through-hole PCB designs.
