TC4086BP, Expandable 4-Wide 2-Input AND-OR-INVERT Gate, DIP-16 Package

The TC4086BP is an expandable 4-wide 2-input AND-OR-INVERT gate integrated circuit, designed for versatile logic operations. It consists of four 2-input AND gates whose outputs are combined using an OR gate, followed by an inverting stage. This configuration allows for complex logic functions in digital circuits. Manufactured using CMOS technology, the TC4086BP offers low power consumption and high noise immunity, making it suitable for a wide range of applications. Its operating voltage range and standard DIP-16 package ensure compatibility with various design requirements.​

Key Features:

• Expandable Logic Configuration: Allows for flexible logic design by combining multiple gates.​
• Low Power Consumption: CMOS technology ensures minimal power usage.​
• High Noise Immunity: Robust performance in noisy environments.​
• Wide Operating Voltage Range: Suitable for various applications.​
• Standard DIP-16 Package: Facilitates easy integration into through-hole designs.​
• Reliable Manufacturer: Produced by Toshiba, ensuring quality and consistency.​

Additional Specifications:

• Package Type: DIP-16
• Product Type: Expandable 4-Wide 2-Input AND-OR-INVERT Gate
• Input Low Voltage: Maximum 1.5V at V_DD = 5V
• Input High Voltage: Minimum 3.5V at V_DD = 5V
• Propagation Delay Time: Typically 50ns at V_DD = 10V
• Logic Gate Type: AND-OR-INVERT
• Supply Voltage: Operates within a range of 3V to 18V
