"The MPLAB PICkit 4 is a powerful and versatile programming and debugging tool that is designed to help engineers quickly and easily program and debug PIC, dsPIC, AVR, SAM and CEC flash microcontrollers and microprocessors. With its powerful 32-bit 300 MHz SAME70 MCU, the PICkit 4 is capable of fast programming speeds, and comes with advanced features like Programmer-to-Go functionality, 4-wire JTAG and Serial Wire Debug with streaming Data Gateway, and a micro SD card slot for holding project code and being self-powered from the target board. Additionally, the PICkit 4 is fully compatible with the MPLAB X IDE v5.30 and earlier, making it easy to use and integrate into your development workflow.

Features:

- Matches silicon clocking speed
*Programs as fast as the device will allow
- Target voltage of 1.20V to 5.5V
*Wide target voltage supports a variety of devices
- Program voltages:
*2.3V to 5.0V - Low voltage and high voltage program entry modes
*1.2V to 2.3V - Low voltage program entry mode only
- Can supply up to 50mA of power to the target
*Can be powered from the target to program in the field
- Portable USB-powered and RoHS-compliant
*Powered by a high-speed USB 2.0, no external power required
*CE and RoHS-compliant
- 8-pin single in-line header
*Supports advanced interfaces such as 4-wire JTAG and Serial Wire Debug with streaming Data Gateway
- Compatibility
*Backward compatible for demo boards, headers and target systems using 2-wire JTAG and ICSP
- Option to be self-powered from the target (2.7V to 5.5V)
- Programmer-to-Go (PTG) support
*SD card slot to holds program data
*Press on the logo to program the target
- Cost effective
*Features and performance at a fraction of the cost of comparable debugger/programmers
- Ease of maintenance and feature upgrade
Add new device support and features by installing the latest version of MPLAB X IDE

Package Contents:

MPLAB PICkit 4 In-Circuit Debugger/Programmer
USB to micro-B USB cable
Warranty card
2 MPLAB PICKit 4 stickers
"
